CaSE Cornerstone Design Project: Gwynns Falls / Leakin Park Bridge Project (IncliNation LLC)
- Program: Civil and Systems Engineering
- Course: EN.560.192 CaSE Design
- Year: 2025
Project Description:
Gwynns Falls/Leakin Park in Baltimore features hiking trails, a nature center, and cultural landmarks. The current elevated boardwalk has been damaged by a fallen tree, and the park’s volunteer group have requested a more resilient replacement. Our design emphasizes accessibility, safety, and constructibility while integrating principles of civil and systems engineering. Graded ramps at each end accommodate cyclists and hikers, with slopes tailored to the bridge’s height and span. Selected 6×6″ support beams and 2×6″ decking simplify construction and ensure durability. Although resilience is a key objective, we decided to not over engineer the structure as it could disrupt local wildlife and detract from the park’s natural beauty. Our design focuses on balance—constructed to withstand environmental stressors, yet minimal to preserve the ecological state of the area. This aligns with the park’s mission to maintain a harmonious relationship between nature and infrastructure.
Project Photo:
The bridge features a modern, sleek design. Wood beams made of 6×6 wood members run parallel to the path, forming the frame and providing structural integrity to support the deck. Beneath, a system of evenly spaced vertical supports holds the bridge, secured by wooden beams on both sides for added stability.
